Surge Limiter Type T2 4P 20kA 1.5kV 350V CL1 2905340

Name: Surge Limiter Type T2 4P 20kA 1.5kV 350V CL1 2905340
Brand: PHOENIX CONTACT

PHOENIX CONTACT

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nSurge arresters C Type 2 4P 20kA 1.5kV 350V VAL-SEC-T2-3S-350-FM 2905340 /T2UK\nParameters:\n\n--Mounting method: DIN 35 mm mounting rail\n-- Size: 3 modules\n-- With remote signaling contact: Yes\n-- Activation indication on the device: Optical\n-- Network layout: Other\n-- Poles: 2\n-- Type 2: Yes\n-- Cross-section of the connected cable (flexible, multi-wire) [mm2]: 25\n-- Cross-section of a rigid cable (single-wire, multi-wire) [mm2]: 35\n-- Rated AC voltage [V]: 240\n-- Protection level LN [kV]: 1.5000\n-- Protection level L-PE/N-PE [kV]: 1.5000\n-- Maximum continuous AC operating voltage [V]: 350\n-- Rated discharge current - peak value (8/20) [kA]: 40\n\nSurge arresters VAL-SEC-T2-3S-350-FM Universal type 2 surge arrester, used as a type of \""surge arrester\"" in all AC installations - especially in industrial ones. The internal 3+1 connection system, suitable for TN-S/TT networks, offers a loweS
